Notes Stack Segment

8086 Microprocessor supports the Word stack. The stack segment parameters tell the assembler
to alert the linker that this segment statement defines the program stack area.

A program must have a stack area in that the computer is continuously carrying on several
background operations that are completely transparent, even to an assembly language
programmer, for example, a real time clock. Every 55 milliseconds the real time clock interrupts.
Every 55 ms the CPU is interrupted. The CPU records the state of its registers and then goes

about updating the system clock. When it finishes servicing the system clock, it has to restore the
registers and go back to doing whatever it was doing when the interruption occurred. All such
information gets recorded in the stack. If your program has no stack and if the real time clock
were to pulse while the CPU is running your program, there would be no way for the CPU to
fi nd the way back to your program when it was through updating the clock. 0400H byte is the

default size of allocation of stack. Please note if you have not specified the stack segment it is
automatically created.

Data Segment
It contains the data allocation statements for a program. This segment is very useful as it shows
the data organization.

Def ning Types of Data

The following format is used for defining data defi nition:
Format for data defi nition:
{Name} <Directive> <expression>

Name: A program references the data item through the name although it is optional.
Directive: Specifying the data type of assembly.
Expression: Represent a value or evaluated to value.
The list of directives are given below:

Directive Description Number of Bytes
DB Defi ne byte 1
DW Defi ne word 2
DD Define double word 4

DQ Define Quad word 8
DT Define 10 bytes 10

DUP Directive is used to duplicate the basic data definition to ‘n’ number of times
ARRAY DB 10 DUP (0)
In the above statement ARRAY is the name of the data item, which is of byte type (DB). This array
contains 10 duplicate zero values; that is 10 zero values.

EQU directive is used to define a name to a constant
CONST EQU 20
Type of number used in data statements can be octal, binary, haxadecimal, decimal and ASCII.
The above statement defines a name CONST to a value 20.
